Product Category

Residential Swimming Pool

1.R32 refrigerant, more environmentally friendly
2. Corrosion resistance of titanium tube heat exchanger
3. High pressure protection function
4. Smart defrosting technology
5. It can heat and cool the pool

Category :
Swimming Pool Heat Pumps
Browse number : ...
Release time : 2025-07-24

Message

Detailed Description

Introduce：

Suitable for family pool use

Feature：

1.R32 refrigerant, more environmentally friendly

2. Corrosion resistance of titanium tube heat exchanger

3. High pressure protection function

4. Smart defrosting technology

5. It can heat and cool the pool

Parameter：

Model		ZKFD-YC-020	ZKFD-YC-030	ZKFD-YC-040	ZKFD-YC-050	ZKFD-YC-060	ZKFD-YC-080	ZKFD-YC-100
Advised pool volume (m³)		30-45m3	40-55m3	50-70m3	65-95m3	80- 1 15m3	1 10- 145m3	1 10- 145m3
Heating temperatuer range		15°C~40°C	15°C~40°C	15°C~40°C	15°C~40°C	15°C~40°C	15°C~40°C	15°C~40°C
Cooling temperatuer range		7°C~35°C	7°C~35°C	7°C~35°C	7°C~35°C	7°C~35°C	7°C~35°C	7°C~35°C
Operating range		- 15°C~43°C	- 15°C~43°C	- 15°C~43°C	- 15°C~43°C	- 15°C~43°C	- 15°C~43°C	- 15°C~43°C
Air 26C Water 26C
capacity(KW)		7.62~1.75	10.21~2.34	13. 12~3.02	16.52~3.79	21.01~4.83	28.23~6.49	28.42~6.53
capacity(KW) in silence mode		6.48~1.75	8.68~2.34	11. 15~3.02	14.06~3.79	17.88~4.83	24.03~6.49	24. 16~6.53
power input(KW)		1. 10~0. 13	1.47~0. 17	1.88~0.22	2.38~0.28	3.03~0.36	4.06~0.48	4.08~0.48
input current (A)		5~0.59	6.69~0.77	8.55~1	10.82~1.28	13.77~1.64	18.45~2. 18	7.28~0.86
power input(KW) in silence mode		0.86~0. 13	1. 15~0. 17	1.44~0.22	1.83~0.28	2.35~0.36	3.06~0.48	3.07~0.48
COP		13.52~6.91	13.54~6.93	13.61~6.98	13.57~6.95	13.56~6.94	13.57~6.95	13.59~6.96
COP in silence mode		13.52~7.51	13.54~7.54	13.61~7.72	13.57~7.68	13.56~7.62	13.57~7.83	13.59~7.88
Air 15C Water 26C
capacity(KW)		5.74~1.33	7.62~1.76	9.73~2.23	12.61~2.87	15.74~3.59	20.68~4.77	20.75~4.79
capacity(KW) in silence mode		4.88~1.33	6.48~1.76	8.28~2.23	10.74~2.87	13.41~3.59	17.61~4.77	17.68~4.79
power input(KW)		1. 16~0. 18	1.54~0.23	1.95~0.29	2.54~0.38	3. 18~0.47	4. 17~0.63	4. 18~0.63
input current (A)		5.27~0.82	7~1.05	8.86~1.32	11.55~1.73	14.45~2. 14	18.95~2.86	7.46~1. 12
power input(KW) in silence mode		0.89~0. 18	1. 18~0.23	1.49~0.29	1.95~0.38	2.44~0.47	3. 19~0.63	3.20~0.63
COP		7.53~4.94	7.58~4.95	7.63~4.98	7.61~4.96	7.57~4.95	7.59~4.96	7.59~4.97
COP in silence mode		7.53~5.46	7.58~5.48	7.63~5.54	7.61~5.51	7.57~5.49	7.59~5.51	7.59~5.53
Air 15C Water 26C (Fix Mode)
capacity (KW)		3.96	5.21	6.75	8.52	10.03	13.68	13.72
power input(KW)		0.71	0.92	1. 17	1.48	1.74	2.39	2.39
COP		5.61	5.69	5.78	5.76	5.75	5.73	5.74
Power supply		220~	220~	220~	220~	220~	220~	380~
Power supply		240V/50Hz	240V/50Hz	240V/50Hz	240V/50Hz	240V/50Hz	240V/50Hz	415V/50Hz
Max power input	KW	2.053	2.853	3.656	3.925	4.985	5.962	5.962
Rated power		1. 16	1.54	1.95	2.54	3. 18	4. 17	4. 18
Rated current		5.27	7	8.86	1 1.55	14.45	18.95	7.46
Fuse or circuit breaker(A)		10	15	20	20	25	30	15
Water flow	m³/h	2.5	3.5	4.5	5.5	6.5	9	9
Refrigerant	R32
Refrigerant volume	g	380	460	850	850	950	1 170	1 170
Min pressure/max pressure		0.2/4.4	0.2/4.4	0.2/4.4	0.2/4.4	0.2/4.4	0.2/4.4	0.2/4.4
Water proof level		IPX4	IPX4	IPX4	IPX4	IPX4	IPX4	IPX4
Pressure loss	(mCE)	0.9	1	1.1	1.1	1.1	1.1	1.2

Company Profile

Shandong Fude New Energy Equipment Co., Ltd. is located in Tengzhou City, Shandong Province. It was established in 2009 with a registered capital of 100.8 million yuan. It is a national high-tech enterprise specializing in research and development, production, sales, service and after-sales of air energy heat pump products. After more than ten years of development, ZKFD has built an air energy industrial park of 140000 square meters and more than 300 employees, laying out the whole air energy industrial chain. At present, it has formed a comprehensive office building, a technology research and development center, a popular science culture center, a comprehensive experimental testing platform, a fully automatic air source heat pump intelligent production line, an evaporator production line, a heat exchanger production line, a sheet metal production line, a spraying production line The air energy industrial park and industrial cluster, including the assembly workshop, can achieve an annual production capacity of 500000 sets and a sales volume of 2 billion. It has more than 30 laboratory groups including CNAS ultra-low temperature air source heat pump laboratory, noise laboratory and drying test laboratory, which are leading in the industry. The company has dominated the northern market, with more than 3000 sales outlets in the country, and provides OEM / ODM services to dealers around the world. It is the largest heat pump industrial park base in northern China.

Packing & Delivery

FAQ

1. who are we?
We are based in Shandong, China, start from 2009,sell to Oceania(20.00%),Western Europe(20.00%),Northern Europe(20.00%),North America(19.00%),Southern Europe(11.00%),Eastern Europe(10.00%). There are total about 201-300 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Swimming Pool Heat Pumps,Fresh Air Products,Heating&Cooling,Commercial Hot Water Products,Residential Hot Water Products

4. why should you buy from us not from other suppliers?
Founded in 2009, ZKFD is one of the largest manufacturers of swimming pool heat pump, residential heating heat pump and heat pump water heater in China.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
