Suitable for large swimming pool, swimming pool, aquaculture plant and other places
| Model | ZKFD-YC-020 | ZKFD-YC-030 | ZKFD-YC-040 | ZKFD-YC-050 | ZKFD-YC-060 | ZKFD-YC-080 | ZKFD-YC-100 | |
| Advised pool volume (m³) | 30-45m3 | 40-55m3 | 50-70m3 | 65-95m3 | 80- 1 15m3 | 1 10- 145m3 | 1 10- 145m3 | |
| Heating temperatuer range | 15°C~40°C | 15°C~40°C | 15°C~40°C | 15°C~40°C | 15°C~40°C | 15°C~40°C | 15°C~40°C | |
| Cooling temperatuer range | 7°C~35°C | 7°C~35°C | 7°C~35°C | 7°C~35°C | 7°C~35°C | 7°C~35°C | 7°C~35°C | |
| Operating range | - 15°C~43°C | - 15°C~43°C | - 15°C~43°C | - 15°C~43°C | - 15°C~43°C | - 15°C~43°C | - 15°C~43°C | |
| Air 26C Water 26C | ||||||||
| capacity(KW) | 7.62~1.75 | 10.21~2.34 | 13. 12~3.02 | 16.52~3.79 | 21.01~4.83 | 28.23~6.49 | 28.42~6.53 | |
| capacity(KW) in silence mode | 6.48~1.75 | 8.68~2.34 | 11. 15~3.02 | 14.06~3.79 | 17.88~4.83 | 24.03~6.49 | 24. 16~6.53 | |
| power input(KW) | 1. 10~0. 13 | 1.47~0. 17 | 1.88~0.22 | 2.38~0.28 | 3.03~0.36 | 4.06~0.48 | 4.08~0.48 | |
| input current (A) | 5~0.59 | 6.69~0.77 | 8.55~1 | 10.82~1.28 | 13.77~1.64 | 18.45~2. 18 | 7.28~0.86 | |
| power input(KW) in silence mode | 0.86~0. 13 | 1. 15~0. 17 | 1.44~0.22 | 1.83~0.28 | 2.35~0.36 | 3.06~0.48 | 3.07~0.48 | |
| COP | 13.52~6.91 | 13.54~6.93 | 13.61~6.98 | 13.57~6.95 | 13.56~6.94 | 13.57~6.95 | 13.59~6.96 | |
| COP in silence mode | 13.52~7.51 | 13.54~7.54 | 13.61~7.72 | 13.57~7.68 | 13.56~7.62 | 13.57~7.83 | 13.59~7.88 | |
| Air 15C Water 26C | ||||||||
| capacity(KW) | 5.74~1.33 | 7.62~1.76 | 9.73~2.23 | 12.61~2.87 | 15.74~3.59 | 20.68~4.77 | 20.75~4.79 | |
| capacity(KW) in silence mode | 4.88~1.33 | 6.48~1.76 | 8.28~2.23 | 10.74~2.87 | 13.41~3.59 | 17.61~4.77 | 17.68~4.79 | |
| power input(KW) | 1. 16~0. 18 | 1.54~0.23 | 1.95~0.29 | 2.54~0.38 | 3. 18~0.47 | 4. 17~0.63 | 4. 18~0.63 | |
| input current (A) | 5.27~0.82 | 7~1.05 | 8.86~1.32 | 11.55~1.73 | 14.45~2. 14 | 18.95~2.86 | 7.46~1. 12 | |
| power input(KW) in silence mode | 0.89~0. 18 | 1. 18~0.23 | 1.49~0.29 | 1.95~0.38 | 2.44~0.47 | 3. 19~0.63 | 3.20~0.63 | |
| COP | 7.53~4.94 | 7.58~4.95 | 7.63~4.98 | 7.61~4.96 | 7.57~4.95 | 7.59~4.96 | 7.59~4.97 | |
| COP in silence mode | 7.53~5.46 | 7.58~5.48 | 7.63~5.54 | 7.61~5.51 | 7.57~5.49 | 7.59~5.51 | 7.59~5.53 | |
| Air 15C Water 26C (Fix Mode) | ||||||||
| capacity (KW) | 3.96 | 5.21 | 6.75 | 8.52 | 10.03 | 13.68 | 13.72 | |
| power input(KW) | 0.71 | 0.92 | 1. 17 | 1.48 | 1.74 | 2.39 | 2.39 | |
| COP | 5.61 | 5.69 | 5.78 | 5.76 | 5.75 | 5.73 | 5.74 | |
| Power supply | 220~ | 220~ | 220~ | 220~ | 220~ | 220~ | 380~ | |
| 240V/50Hz | 240V/50Hz | 240V/50Hz | 240V/50Hz | 240V/50Hz | 240V/50Hz | 415V/50Hz | ||
| Max power input | KW | 2.053 | 2.853 | 3.656 | 3.925 | 4.985 | 5.962 | 5.962 |
| Rated power | 1. 16 | 1.54 | 1.95 | 2.54 | 3. 18 | 4. 17 | 4. 18 | |
| Rated current | 5.27 | 7 | 8.86 | 1 1.55 | 14.45 | 18.95 | 7.46 | |
| Fuse or circuit breaker(A) | 10 | 15 | 20 | 20 | 25 | 30 | 15 | |
| Water flow | m³/h | 2.5 | 3.5 | 4.5 | 5.5 | 6.5 | 9 | 9 |
| Refrigerant | R32 | |||||||
| Refrigerant volume | g | 380 | 460 | 850 | 850 | 950 | 1 170 | 1 170 |
| Min pressure/max pressure | 0.2/4.4 | 0.2/4.4 | 0.2/4.4 | 0.2/4.4 | 0.2/4.4 | 0.2/4.4 | 0.2/4.4 | |
| Water proof level | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | IPX4 | |
| Pressure loss | (mCE) | 0.9 | 1 | 1.1 | 1.1 | 1.1 | 1.1 | 1.2 |
