Household Cooling&Heating EVI and advanced frequency conversion technology

Adopt the EVI and advanced frequency conversion technology.
Function: Heating,Cooling and Domestic hot water.
  • Detailed Description

Parameters

Unit Mode

ZKFD-BPLN-030CD

ZKFD-BPLN-050CD

ZKFD-BPLN-060CD

ZKFD-BPLN-080CD

ZKFD-BPLN-100CD

ZKFD-BPLN-150CD

Horse Power

3

5

6

8

10

15

Rated Voltage

220V

380V

Heating Capacity at Air 7℃,water 50℃ IN,55℃ OUT

Heating Capacity(KW)

9.72

16.20

19.44

25.92

31.89

41.40

Power Input(KW)

2.91

4.85

5.82

7.76

9.55

12.39

COP

3.34

3.34

3.34

3.34

3.34

3.34

Cooling Capacity at Air 35℃,water 12℃ IN,7℃ OUT

Cooling Capacity(KW)

6.53

10.88

13.55

15.81

21.77

31.61

Rated Power Input(KW)

2.38

4.03

4.88

5.73

8.07

11.46

EER

2.74

2.70

2.78

2.76

2.70

2.76

Max.Power Input(KW)

3.32

5.54

6.64

8.86

12.18

17.72

Max. Current(A)

15.10

25.17

30.20

40.27

21.77

31.68

Refrigerant

R32/R410A

Compressor

Full DC Inverter Compressor

Heat Exchanger

                 Plate Heat Exchanger

Dimension

(L×W×H)(mm)

1100*490*860

1100*490*1265

1100*490*1410

1100*490*1560

1424*514*1688

1424*514*1688

Net Weight (KG)

100

135

147

154

210

235



Detailed Features:

EVI Technology

EVI means “Enhanced Vapor Injection” and it makes our low-temperature heat pumps to achieve higher performance at lowest temperatures -35°C and work stably and keep the high efficiency.

Full DC Inverter Technology

Because of a full DC inverter twin-rotary compressor with an inverter brushless motor, it can adjust the temperature automatically,and makes the user more comfortable.

Low GWP Refrigerant R32 / R290

GWP means Global Warming Potential,R32/R290 has much lower GWP comparing to the other refrigerants used widely nowadays.

Super Low Noise

Our heat pumps adopt the reinforced sound reduction measures such as brushless DC Inverter fans and dual shock absorption of compressor,making the operation quietest.

Touch Screen LCD Display

It’s easier to be installed and used for display the water temperature curve,easy timing,one-key mute etc.

IOT FUNCTION

The users can control some functions(Turn on/off and select working modes and realize the function of real-time alarm and display automatically ) of the heat pumps from IOT function.

Connection Diagram for Heating and Cooling Solution:
